TOOL STAGES CHART

The Flux Tool Stages Chart is a visual representation that outlines the different phases involved in the flux tool process. This chart serves as a guide for understanding the sequential steps required to achieve optimal results in various applications, from soldering and electronics to metalworking and jewelry making. Each stage is crucial, ensuring efficiency, precision, and quality in the final output.

SEND ENQUIRY
Vincent Engineering TOOL NAME & PROCESS STAGE: BLANK
COLOUR CODE:
S.NO PART NO PART NAME MODEL THICK
1 B-4170059 CABLE GUIDE N36 1 MM
2 P 3090209 TUBE FOOT REST LEFT XLN 1.60 MM
3 P 3090089 TUBE FOOT REST RIGHT U162 1.60 MM
4 N 9090459 PLAT CHAIN CASE FITTING INNER N40 1.60 MM
5 G-4300289-4 BUMPER REINFORCEMENT BRKT N46 1.60 MM
6 P 3090319 BRKT TORQUE LINK U162 2 MM
7 P 3300640/1 PILLION HANDLE TOP MTG BRKT U162 2 MM
8 N 90901439 GUSSET BRIDGE LEFT U86 2 MM
9 N 9091429 GUSSET BRIDGE RIGHT U86 2 MM
10 591850/A RING CAT 2 MM
11 K 6050390/17 BRKT MTG TOP LEFT N118 2 MM
12 K 6050390/18 BRKT MTG TOP RIGHT N118 2 MM
13 K 6050390/20 BRKT MTG BOTTOM RIGHT N118 2 MM
14 K 6121490 FOOT REST COM PILLION 2 MM
15 P 6090109 BRKT CHAIN CASE MTG FRONT U162 2 MM
Vincent Engineering TOOL NAME & PROCESS STAGE: BLANK
COLOUR CODE:
S.NO PART NO PART NAME MODEL THICK
16 G 5221229 BRKT RH SOFT TOP UPPER N46 2 MM
17 G 5220889 BRKT LH SOFT TOP UPPER N46 2 MM
18 G 5220189 SOFT TOP RR BRKT “D” N46 2 MM
19 G 5221239 SOFT TOP RR CROSS MEMBER DC JOINT BRKT N46 2 MM
20 K 6121639 RENIF BRKT STAND LEFT WEGO 2.30 MM
21 K 6121649 RENIF BRKT STAND RIGHT WEGO 2.30 MM
22 V 1010600430-1 VST TILLER FUE TANK BRKT 2.30 MM
23 P3090290 TORQUE LINK REAR (SCALE) U162 2.50MM
24 N 3090079 BRKT REAR SHOCKABSORBER (REG) N40 2.50MM
25 N 8221080-5 BRKT MTG 2 FRAME (NEW SAREE GUARD) U261 2.50MM
26 N 8090679 BRKT CHAIN CASE MTG FRONT N45 2.50MM
27 N 8090689 BRKT CHAIN CASE MTG REAR N45 2.50MM
28 N 8091229 BRKT REAR SHOCKABSORBER (N104) N 104 2.50MM
29 N 9300010/1 N 17 TOP MTG CRASH GUARD N17 2.50MM
30 N 9223970-2 U129 FOOT REST BRKT BOTTOM U129 2.50MM
Vincent Engineering TOOL NAME & PROCESS STAGE: BLANK
COLOUR CODE:
S.NO PART NO PART NAME MODEL THICK
31 N-3220810-10 U177 BRKT FOOT REST U177 2.50MM
32 N 9091409 RENIF SWING ARM ‘R’ U86 2.50MM
33 G-5124179 BRKT ENGINE MRG REAR LEFT AUTO 2.50MM
34 G-2090300-4 CLOSE PLATE MAIN ARM AUTO 2.50MM
35 G-2090300-5 CLOSE PLATE SUPPORT ARM AUTO 2.50MM
36 G-4300270-2 STAY BUMPER CABIN MTG BRKT N46 2.50MM
37 N-9090389 RENI SWIMARM PATCH LH N17 2.50MM
38 M-7090069 RENI SWIMARM PATCH RH N17 2.50MM
39 592629/A RING EXHAUST PIPE 2.50MM
40 591305/B BRKT LINER PLATE 2.50MM
41 591404/A TOOL BOX TOP MTG BRKT 2.50MM
42 5941542/A BRAKE LAMP SWITCH BRKT(HEMA) 2.50MM
43 XLNBFRRM002/A2 BRKT FOOT RST BAR 2.50MM
44 N40CSRM004 BOOT CENTER STAND LEFT 2.50MM
45 N40CSRM005 BOOT CENTERSTAND RIGHT 2.50MM
Vincent Engineering TOOL NAME & PROCESS STAGE: BLANK
COLOUR CODE:
S.NO PART NO PART NAME MODEL THICK
46 N40PFRRM006 BRKT SAREE GUARD MTG N40 2.50MM
47 P 6120790-2 BRKT FOOT REST U162 2.50MM
48 N 3121009 REINFORCMENT N17 2.50MM
49 K 6121119 BRKT PROP STAND ‘L’ PLATE 2.50MM
50 M 7090669 NEW CHAIN CASE MTG FRONT 2.50MM
51 N 5091439 REIN  ‘L’ REAR SWING ARM U223 2.50MM
52 N 9092059 BRKT RR SHOCKABSORBER LH 2.50MM
53 N 9092169 BRKT RR SHOCKABSORBER RH 2.50MM
54 N 8300030-3 U261 BRKT TOP MTG CRASH GUARD U261 2.50MM
55 N 6090099 U135 BRKT REAR SHOCKABSORBER LH U135 2.50MM
56 594364/C BRKT SHOX MTG 3MM
57 N-3220810-2 U177 BRKT TOP U177 3MM
58 N 9220800-7 BRKT MTG FRAME U180 3MM
59 580090/C SWING ARM BRKT INNER RIGHT (HEMA) NT51 3MM
60 580092/C SWING ARM BRKT INNER LEFT (HEMA) NT51 3MM
Vincent Engineering TOOL NAME & PROCESS STAGE: BLANK
COLOUR CODE:
S.NO PART NO PART NAME MODEL THICK
61 580091/C SWING ARM BRKT OUTER RIGHT (HEMA) NT51 3MM
62 580093/C SWING ARM BRKT OUTER LEFT (HEMA) NT51 3MM
63 591292/C BRKT RESONATOR BOX 3MM
64 N40CSRM006 STOP CENTER STAND (FORMING PIECE) 3MM
65 WEGOCSRM014 LADY FOOT REST WEGO 3MM
66 N40CSRM008 N40 GUSSET CENTER STAND N40 3MM
67 P 6120790-3 TUBE HOLDER FOOT REST U162 3MM
68 580090/C SWING  ARM BRKT INNER RIGHT (BADVEE) 3MM
69 580092/C SWING ARM BRKT INNER LEFT (BADVEE) 3MM
70 580091/C SWING ARM BRKT OUTER RIGHT (BADVEE) 3MM
71 580093/C SWING ARM BRKT OUTER LEFT (BADVEE) 3MM
72 K 6120789 BRKT SHOCK ABSORBER MTG 3MM
73 27620000 LOWER CAP EZGO 3MM
74 N 2100039 PLATE UPPER BRKT 3MM
75 N 2100129 RENIF UPPER BRKT (WASHER) 3MM
Vincent Engineering TOOL NAME & PROCESS STAGE: BLANK
COLOUR CODE:
S.NO PART NO PART NAME MODEL THICK
76 MC 2012 INNER PLATE 3MM
77 M 8220190-2 BRKT MTG SAREE GUARD (SMALL) N43 3.20MM
78 M 8220190-3 BRKT MTG SAREE GUARD (BIG) N43 3.20MM
79 N 9220740-2 U68 BRKT TOP MTG CRASH GUARD U68 3.20MM
80 G 2090300/6 BRKT SUSPENSION MTG REAR LH Auto 3.20MM
81 G 2090300/6 BRKT SUSPENSION MTG REAR RH Auto 3.20MM
82 G 2090300-8 PLATE REAR EXPORT-1 Auto 3.20MM
83 591244/C BRKT TOOL BOX BOTTOM MTG 3.20MM
84 591291/A BRKT BATTERY CARRIER 3.20MM
85 N40PFRM005 HOLDER PILLION FOOT REST 3.20MM
86 P 6090139 U162 PLATE SWING ARM RIGHT U162 4 MM
87 P 6090119 U162 PLATE SWING ARM LEFT U162 4 MM
88 P-1090179 PLATE SWING ARM RIGHT (XLN) XLN 4 MM
89 P-1090169 PLATE SWING ARM LEFT (XLN) XLN 4 MM
90 P-090069 PLATE SWING ARM ‘A’ BRKT XLN 4 MM
Vincent Engineering TOOL NAME & PROCESS STAGE: BLANK
COLOUR CODE:
S.NO PART NO PART NAME MODEL THICK
91 N 8090379 N40 BRKT TORQUE LINK N40 4 MM
92 3202320 HEMA BRACKET (U54) U54 4 MM
93 592889/B BRKT SILENCER MTG (NEW) 4 MM
94 591369/B 4MM BRACKET (ENFIELD) 4 MM
95 591652/A PLATE PEDAL STOPPER 4 MM
96 N 2121229 PLATE STEERING LOCK (REG) 4 MM
97 N 9120939 PLATE STEERING LOCK (SMALL) 4 MM
98 A 10105-1 OUTER SHELL UPPER 4 MM
99 M 1120869 SEAT STEERING INNER RACE LOWER CUP 4 MM
100 K 6121589 GUSSET BRKT PROP STAND 4 MM
101 N 8300030-2 BRKT MTG CRASH GUARD (OLD) U261 4.50 MM
102 N 9223280/3 U129 BRKT TOP MTG CRASH GUARD U129 4.50 MM
103 N 9223280/2 U129 BRKT BOTTOM MTG CRASH GUARD U129 4.50 MM
104 N 9220740/1 U68 BRKT BOTTOM MTG CRASH GUARD U68 4.50 MM
105 591651 CENTER STAND BRKT LEFT (HEMA) 5 MM
Vincent Engineering TOOL NAME & PROCESS STAGE: BLANK
COLOUR CODE:
S.NO PART NO PART NAME MODEL THICK
106 591650 CENTER STAND BRKT RIGHT(HEMA) 5 MM
107 591651 CENTER STAND BRKT LEFT (BADVEE) 5 MM
108 591650 CENTER STAND BRKT RIGHT(BADVEE) 5 MM
109 MRP 214 SIDE PLATE (MRP) 5 MM
110 MC 1404 FEB PLATE (IRP) 5 MM
111 MRP 829 PLATE 5 MM
112 HTA 3566 INSERT JOINT CARBURATOR 5 MM
113 MC 1112 BUMPER FRONT AXLE 5 MM
114 MECH-38A PLATE 5 MM
115 MECH-38B PLATE 6 MM
116 K 6170290-8 BRKT PROP STAND (NEW STAR) 6 MM
117 MRP 356 PLATE 6 MM
118 MRP 803 PLATE 6 MM
